Manufacturer and Supplier of Digital Signage ,Visual Displays and Monitors.
8.4″ Digital Signage
8.4″ Digital Signage
In your store, showroom or on your exhibition stand everything is about getting the attention, with our Digital Advertising Displays you can significantly higher your sales.Surveys proof that 75% of all buying decisions are made in the store with our Digital Advertising Displays it is possible to show the right commercial, at the right time, at the right place, to the right people. Our 8 Inch Digital Advertising Display works fully standalone and only needs a power outlet. After putting in the memory card the Digital Advertising Display will automatically recognize which files it can play, this can be Photo, MP3 and Video files. You can even combine photos with music.
We are pleased to let you know that we added a number of new features, including:
We added a number of new features, including:
1. Auto start when power is turned on, Auto repeat play function
2. Auto on-off 3 times per day
3. Auto-update content to CF card via USB drive
4. Plays favorite files
5. External motion detector which control audio (optional)
6. External motion detector which control Video/audio (optional)
There is no product in the market that is so feature rich than the SUN-SG8A series
Panel interface |
8" LCD Digital Panel 1280 (H) x 3 (RGB) x 1024 (V) |
Video Format |
M-JPEG / MPEG1 / MPEG2 / MPEG4/MP3 (see Table 1) |
Music Playback |
Stereo MP3 format decoding (32Kbps ~256Kbps) |
Photo Viewer |
JPEG & BMP&TIFF (max. 5120x3840) |
Expansion Memory |
Card Reader (CFI, II/ MD /MS/ MS Pro/ SD/ XD / MMC) |
Brightness/Contrast ratio |
420 cd/m2 / 350:1 |
USB port |
USB i2.1 Host port |
Timer |
Time, Calendar, Clock Alarm, Auto reserve Power on & off |
Speaker Driver |
8 ohm 1W Square High Quality speakers x 2 paces |
I/O connector |
USB host connector,Audio/Video connector,DC-IN Jack |
LED Indicators |
Power LED (Green / Orange) |
Control Button |
8 control keys (Power, Time and 6 for Media-Player control) |
|
Media-Player function(Home, Left, Right, Enter, Volume+, Volume-) |
Remote Controller |
Yes |
Power Adapter Audio Format |
DC 12V 3A 2CH audio D/A converter |
Friendly User Interface |
Photo Slide show interval time setting 1 / 3 / 5 / 10 sec |
|
12 photo slide transition selection |
|
11OSD language select |
|
English / French / German / Italian / Portuguese, Spanish / Chinese / Japanese |
|
Photo and Movie digest style from 2x2 to 5x5 matrix |
|
MP3 and Movie repeat select off / one / all |
|
MP3 equalizer display |
|
File library for file select |
|
Calendar with month from 2005 to 2020 |
|
Save about 20 favorite photos in DRAM |
|
File copy and rename by remote controller Copy file between different memory cards |
Specification is subjected change prior any notice. |
How does this technology work?
When a moving object is detected by PIR (Passive InfraRed sensors), the Digital Signage System will either turn on the LCD backlight or boot up the system. At this moment, a clock starts to count down. If no moving object is detected in a pre-defined period of time, the Digital Signage System will either turn off the LCD backlight or shut down until a moving object is detected again.
Benefits
Save power
Grab more attention
Carry out the most effective advertising
Application
Indoor Advertising
Retail Store
Shopping Mall
Public Bulletins
In the store the employees can be annoyed by the sound used by digital signage systems, using motion sensor controlled sound solves this problem.
